Product Type: 8018/3113-al-6
Art. No.: 269788
Highlights
For installation in enclosure wall, enclosure cover, panels or control cabinets
Installation using a single dia. 30 mm hole
Beneficial LED technology: Extremely long service life, high luminance, low heat build-up
Reliable explosion protection thanks to flameproof contact elements and lighting elements
Functional Description
R. STAHL Series 8018 LED illuminated pushbuttons switch load, control and signal circuits and show command statuses via a light signal, the colour of which can be determined using the colour filter included in the delivery: Red, yellow, green, blue or white. The long-lasting LEDs ensure high luminance and minimal heat build-up. The buttons are supplied with a connection cable.
